Product Details:
|
| Injection Pressure: | 165 | Screw Speed: | 150 |
|---|---|---|---|
| Clamp Tonnage: | 6500 | Toggle Stroke: | 890 |
| Space Between Tie Bars: | 890*890 | Max.Mold Height: | 900 |
| High Light: | plastic moulding machine,automatic injection moulding machine |
||
Providing better lubrication and lower lubrication consumption. A smooth operation leads to longer lifetime of the clamp. Less maintenance required.
Due to new toggle design with optimized kinematics.
Take 200-ton clamping unit for example
Vm: Moving speed of movable platen
Vo: Moving speed of oil cylinder
The rigid one-piece injection base supports the common slide rail for injection and screw movements.
Highly optimized servo-hydraulic technology, with improved efficiency for lower energy consumption.
| SPECIFICATION | HJF650 | ||||
| Screw Type | A | B | C | D | |
| Screw Diameter | Mm | 90 | 95 | 100 | 105 |
| Screw L/D Ration | L/D | 20 | 19 | 18 | 17.1 |
| Shot Size(Theoretical) | cm3 | 2800 | 3117 | 3454 | 3808 |
| Injection Weight(PS) | g | 2517 | 2805 | 3108 | 3427 |
| Injection Rate | g/s | 552 | 612 | 679 | 748 |
| Injection Pressure | MPa | 184 | 165 | 149 | 135 |
| Screw Speed | rpm | 150 | |||
| Clamping Force | KN | 6500 | |||
| Opening stroke | Mm | 890 | |||
| Space Between Tie Bars | mm | 890*890 | |||
| Max.Mold Height | mm | 900 | |||
| Min.Mold Height | mm | 350 | |||
| Ejector Stroke | mm | 250 | |||
| Ejector Tonnage | KN | 150 | |||
| Max.Pump Pressure | MPa | 16 | |||
| Pump Motor Power | KW | 55 | |||
| Heater power | KW | 42.95 | |||
| Machine Dimension(L*W*H) | M | 10.2*2.24*2.71 | |||
| Machine weight | T | 28 | |||
| Oil Tank Capacity | L | 1300 | |||
