Product Details
Place of Origin: China
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF780
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Standard Export Package
Delivery Time: 30 days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 5000pcs per year
Structure: |
Horizontal Injection Molding Machine |
Usage: |
Electric Parts |
Machine Weight:: |
37T |
Clamping Force:: |
7800KN |
Space Between Tie Bar: |
980*950mm |
Pump Motor Power: |
37+30KW |
Structure: |
Horizontal Injection Molding Machine |
Usage: |
Electric Parts |
Machine Weight:: |
37T |
Clamping Force:: |
7800KN |
Space Between Tie Bar: |
980*950mm |
Pump Motor Power: |
37+30KW |
plastic nursery pots injection molding machine manufacturer cheap tool mould production line in ningbo for sale
Characteristic
1.Strengthen locking structure
Optimized special locking system to reach efficient and fast production.
2. Centralized lubrication,reliable protection
Configuring rational centralized lubrication, providing more professional, better lubrication to make machine more cleaner.
3. Professional templates optimized design
Template by advanced finite element analysis software to optimize design, high rigidity, high strength, to meet the rapid impact conditions demand.
4. Powerful, friendly control system
Adopts professional controller and friendly interface, easy and fast operation, with good reliability.
5. New type screw driving system
Spline connection for screw and oil motor, smooth and reliable transmission, big transfer torque, easy disassembly.
6. Excellent injection performance
Double cylinder injection, entire floor-guided, reliable and stable.
7. Superior clamping system
Adopts optimized connection rod structure, faster and smoother operation.
8. New frame structure
Simple and generous appearance, machine body force reasonable and stronger.
9. Professional plasticizing system
Suitable for different types of plastic raw material with professional plasticizing and heating system, good plasticizing performance.
Using the servo motor oil esectriciyt composite sturcture, high response, low noile and excellent
electricity -saving performance.
■ Computer Controller PLC
Professional injection moulding machine controller with software and hardware of industrial standard is convenient to expansion and revision of performance.
Adopting double CPU control makes high speed.
Mainly adopting PID control, the control accuracy reaches±1°.
Has the function of network management, improving efficency.
■ The Mould Adjusting Units
The automatic mold adjusting device driven by hydraulic motor adopts gear coupling drive, features steadiness, high-efficiency and saving mold loading time.
| SPECIFICATION | HJF-780 | ||||
| A | B | C | D | ||
| Screw Diameter | Mm | 90 | 95 | 105 | 110 |
| Screw L/D Ration | L/D | 23.2 | 22 | 19.9 | 19 |
| Shot Size(Theoretical) | cm3 | 2924 | 3258 | 3981 | 4369 |
| Injection Weight(PS) | g | 2632 | 2933 | 3583 | 3932 |
| Injection Rate | g/s | 574 | 640 | 781 | 858 |
| Injection Pressure | MPa | 195 | 175 | 143 | 130 |
| Screw Speed | rpm | 115 | |||
| Clamp tonnage | KN | 7800 | |||
| Opening stroke | Mm | 950 | |||
| Space Between Tie Bars | mm | 980*950 | |||
| Max.Mold Height | mm | 960 | |||
| Min.Mold Height | mm | 400 | |||
| Ejector Stroke | mm | 280 | |||
| Ejector Tonnage | KN | 186 | |||
| Max.Pump Pressure | MPa | 16 | |||
| Pump Motor Power | KW | 37+30 | |||
| Heater power | KW | 56.7 | |||
| Machine Dimension(L*W*H) | M | 11.43*2.40*3.14 | |||
| Machine weight | T | 37 | |||
| Oil Tank Capacity | L | 1500 | |||
