Product Details
Place of Origin: CHINA
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF200
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Standard Export Package for Injection Machine
Delivery Time: 20-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 set/sets per month
Voltage: |
Customed Avaiable |
Used For: |
Plastic Products |
Motor: |
Servo & Standard & Variable Pump |
Keyword: |
Energy Saving |
Warranty: |
18 Months |
Plastic Type: |
Thermoplastic |
Certification: |
CE ISO9001 |
Voltage: |
Customed Avaiable |
Used For: |
Plastic Products |
Motor: |
Servo & Standard & Variable Pump |
Keyword: |
Energy Saving |
Warranty: |
18 Months |
Plastic Type: |
Thermoplastic |
Certification: |
CE ISO9001 |
Hydraulic closed loop and motor speed closed loop is realized by control system with the features of high repetition, high linearity, high linearity, high efficiency, high precision, fast response, low rejection rate,low noise, low vibration and long service life, High-rigidity template design with T shot andordinary threaded hole facilitates the mold installtion. Oil filter equipment of high performance and high precision can keep the grease within NAS8. Color control system is adopted.
2. Injection Unit Features
2.1 Injection unit adopts duble-cylinder design, more higher injection pressure, more simpler structure and lower malfunction rate.
2.2 Enlarged-cylinder, adopting two -cylinder design,effectively prevent the adhesive-material leaking phenomenon because of the machine vibration or other reasons when the nozzle is under high-speed operation.
2.3 Adopting graphite bush, improving the wear-resistance, reducing the frequency of using lubrication oil effectively improve the cleanness of the injection part.
2.4 Injection cylinder adopts low-frictional seals, improving the response rate and improve the stability under the complicated processes of injection.
2.5 Bridge-style design, for different L/D plastic parts.
| SPECIFICATION | HJF-140 | |||
| A | B | C | ||
| Screw Diameter | Mm | 38 | 42 | 45 |
| Screw L/D Ration | L/D | 22.1 | 21.6 | 19.5 |
| Shot Size(Theoretical) | cm3 | 193 | 227 | 278 |
| Injection Weight(PS) | g | 176 | 206 | 252 |
| Injection Rate | g/s | 94 | 105 | 135 |
| Injection Pressure | MPa | 205 | 159 | 140 |
| Screw Speed | rpm | 0~220 | ||
| Clamp tonnage | KN | 1400 | ||
| Opening stroke | mm | 380 | ||
| Space Between Tie Bars | mm | 420*420 | ||
| Max.Mold Height | mm | 450 | ||
| Min.Mold Height | mm | 170 | ||
| Ejector Stroke | mm | 120 | ||
| Ejector Tonnage | KN | 33 | ||
| Max.Pump Pressure | MPa | 16 | ||
| Pump Motor Power | KW | 13 | ||
| Heater power | KW | 7.2 | ||
| Machine Dimension(L*W*H) | M | 4.5*1.2*1.7 | ||
| Machine weight | T | 4.2 | ||
| Oil Tank Capacity | L | 230 | ||
Design is one of the most important facets of the production process because it’s the earliest opportunity to prevent expensive mistakes later on. (Of course, determining whether you have a good idea in the first place is also important, but more on that here.) There are many objectives to design for: function, aesthetics, manufacturability, assembly, etc. The right design is one that accomplishes the required objectives to a satisfactory level, but it may take a lot of creativity to get there. Product design is most often accomplished with computer aided design (CAD) software, like SolidWorks. (Click here for nine pro tips on how to best use SolidWorks in design and engineering.) Proficiency with CAD software is vital because it allows for quicker iterations and more accurate prototyping if necessary.
