Product Details
Place of Origin: CHINA
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF360
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Standard Export Package for Injection Machine
Delivery Time: 20-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Set/Sets per Month
Voltage: |
Customed Avaiable |
Used For: |
Plasic Products |
Motor: |
Servo & Standard & Variable Pump |
Keyword: |
Energy Saving |
Warranty: |
18 Months |
Plastic Type: |
Thermoplastic |
Certification: |
CE ISO9001 |
Voltage: |
Customed Avaiable |
Used For: |
Plasic Products |
Motor: |
Servo & Standard & Variable Pump |
Keyword: |
Energy Saving |
Warranty: |
18 Months |
Plastic Type: |
Thermoplastic |
Certification: |
CE ISO9001 |
Runnerless injection mould
Non-runner injection mold is a method of adiabatic heating of the runner, which keeps the plastic between the nozzle and the cavity of the injection machine in a melting state, so that there is no pouring system condensate when the parts are removed from the open mold. The former is called adiabatic runner injection mould, while the latter is called hot runner injection mould.
Right Angle Injection Mold
Right-angle injection moulds are only suitable for angular injection moulding machines. Unlike other injection moulds, the direction of feeding is perpendicular to that of opening and closing moulds. Its main channel is located on both sides of the moving and fixed parting surface, and its cross-sectional area is usually unchanged, which is different from other injection moulds. In order to prevent the wear and deformation of the nozzle and the inlet of the main channel, replaceable runner inserts can be set at the end of the main channel.
Injection Mold of Demoulding Mechanism on Fixed Mold
In most injection moulds, the demoulding device is installed on the side of the moving mould, which is conducive to the ejection device in the opening and closing system of the injection moulding machine. In actual production, because some plastic parts are limited by shape, it is better to leave the plastic parts on the side of the fixed mould for forming. In order to make the plastic parts come out of the mould, it is necessary to set a demoulding mechanism on the side of the fixed mould.
| SPECIFICATION | HJF-180 | |||
| A | B | C | ||
| Screw Diameter | Mm | 42 | 45 | 50 |
| Screw L/D Ration | L/D | 22.5 | 20 | 18.8 |
| Shot Size(Theoretical) | cm3 | 304 | 349 | 431 |
| Injection Weight(PS) | g | 274 | 314 | 388 |
| Injection Rate | g/s | 108 | 128 | 158 |
| Injection Pressure | MPa | 202 | 159 | 140 |
| Screw Speed | rpm | 0~185 | ||
| Clamp tonnage | KN | 1800 | ||
| Opening stroke | Mm | 430 | ||
| Space Between Tie Bars | mm | 470*470 | ||
| Max.Mold Height | mm | 500 | ||
| Min.Mold Height | mm | 180 | ||
| Ejector Stroke | mm | 130 | ||
| Ejector Tonnage | KN | 45 | ||
| Max.Pump Pressure | MPa | 16 | ||
| Pump Motor Power | KW | 15 | ||
| Heater power | KW | 7.5 | ||
| Machine Dimension(L*W*H) | M | 5.1*1.4*1.9 | ||
| Machine weight | T | 5.5 | ||
| Oil Tank Capacity | L | 240 | ||
