Precision Thermoplastic Plastic Injection Molding Machine CE ISO9001 Listed

1, open mold, lock mode, thimble and other actions using high-precision screw nut, transmission accuracy 0.01mm.

2. Linear guideway, which transforms the traditional reciprocating sliding guidance into rolling guidance, improves the positioning accuracy, reduces the cost of machinery and greatly saves electricity, can maintain high precision for a long time.

3, adopt a new type of force sensor to accurately control back pressure to achieve stable precision injection molding.

4, synchronous belt pulley and synchronous belt, simple structure, easy installation, high transmission accuracy and low noise.

5. Adopt centralized lubrication and positive displacement proportional distributor to ensure that every point is fully lubricated.

Check ring – as the name suggests, the function of the check ring is to stop the reverse. It is a part to prevent plastic melt from being leaked in the course of injection.
Ejection nozzle

The nozzle is the transition part connecting the material barrel and the mould.

flange
The flange is a part that connects the nozzle and the barrel. It only acts as a channel in the plasticizing injection process of plastics.

Feeding hopper
The hopper is a part for storing plastic materials, and some hoppers are made of drying hoppers by adding heating and blowing devices to the hopper.

The principle of electric control for all electric injection molding machine:
Servo system: It is an automatic control system that makes the output of the object such as position, orientation and state can follow any change of the input target. The main task of the servo system is to amplify, transform and adjust the power according to the control command, which makes the torque, speed and position control of the driving device very flexible and convenient.
