Product Details:
|
| Structure: | Vertical Injection Molding Machine | Usage:: | Electric Parts |
|---|---|---|---|
| Machine Weight:: | 6t | Clamping Force:: | 1800KN |
| Space Between Tie Bar: | 470mm*470mm | Pump Motor Power: | 15kw |
| High Light: | 1800KN Pet Injection Moulding Machine,15kw Pet Injection Moulding Machine,470mm*470mm Injection Moulding Machine |
||
Propoffional pressure and speed control
Oil suck filter
Oil temperature control and alarm
By-pass oil filter
Hydraulic closed loop and motor speed closed loop is realized by control system with the features of high repetition, high linearity, high linearity, high efficiency, high precision, fast response, low rejection rate,low noise, low vibration and long service life, High-rigidity template design with T shot andordinary threaded hole facilitates
| SPECIFICATION | HJF-180 | |||
| A | B | C | ||
| Screw Diameter | Mm | 42 | 45 | 50 |
| Screw L/D Ration | L/D | 22.5 | 20 | 18.8 |
| Shot Size(Theoretical) | cm3 | 304 | 349 | 431 |
| Injection Weight(PS) | g | 274 | 314 | 388 |
| Injection Rate | g/s | 108 | 128 | 158 |
| Injection Pressure | MPa | 202 | 159 | 140 |
| Screw Speed | rpm | 0~185 | ||
| Clamp tonnage | KN | 1800 | ||
| Opening stroke | Mm | 430 | ||
| Space Between Tie Bars | mm | 470*470 | ||
| Max.Mold Height | mm | 500 | ||
| Min.Mold Height | mm | 180 | ||
| Ejector Stroke | mm | 130 | ||
| Ejector Tonnage | KN | 45 | ||
| Max.Pump Pressure | MPa | 16 | ||
| Pump Motor Power | KW | 15 | ||
| Heater power | KW | 7.5 | ||
| Machine Dimension(L*W*H) | M | 5.1*1.4*1.9 | ||
| Machine weight | T | 5.5 | ||
| Oil Tank Capacity | L | 240 | ||
12.The Hydraulic Units
High efficiency, Energy-saving and high precise proportional pressure and flow variable displacement pump system make the out of the hydraulic system matching the required power for entire machine operation without loss of high pressure throttle and overflow energy. As comparedwith constant displacement pump, it saves power by 30%~60%. A motor with same power may be fitted with an oil pump of bigger displacement and thus accelerates the speed of machine.Besides, the low oil temperature will prolong the service life of sealing elements.
Buffer device is used in every mold opening and clamping oil way to ensure steady mold opening and clamping operation without any impact.Besides, differential mold clamping operation is fitted to ensure high production efficiency.
13.The Machine Introduction
The machine use the high-performance servo dynamic control system,the oil pump as the power source,having the characteristics as follow:high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.
14.Some of the important features:
Clamping system: Faster response, steable and high rigidity.
Injection system: Accurate and flexible, lower rejection rate.
Control system: omputer and simple operation,molding data memory system.
Power system: Energy saving, high efficient and precise.
Metal parts: The thickness of our frame, metal plate and wallboard are thicker than other company.
Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production.
Visiable lubrication system: on time clean, avoid cast steel parts abrasion and broken.
Oil treasure: Filter of hydraulic oil, good for pump and valves.
Long working life: Imported spare parts and updated version.
