CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force

China CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier
CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force supplier

Large Image :  CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force

Product Details:

Place of Origin: Zhejiang ,China
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF240

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard Export Package
Delivery Time: 30 days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 5000pcs per year
Contact Now
Detailed Product Description
Structure: Horizontal Injection Molding Machine Usage:: Electric Parts
Machine Weight:: 7T Clamping Force:: 2400KN
Space Between Tie Bar: 530*510mm Pump Motor Power: 18.5kw

plastic tabplastic CNC injection molding machine plastic battery pull tab China manufacturing companies hydraulic



High Energy saving
Under the ideal working state, Power consumption is 40% less than that of variable displacement pump and 70% less than that of fixed displacement pump, save the cost effectively.
High precision
Precise control of low pressure & low flow, repeating precision is less than 0.5%. Weight error of the products is 0.4%~0.7%, with semi-close loop system nearly.
Fast response
With steady capability, servo gearshift dynamical control system has equipped with pressure feedback device with high precision and sensitivity, which forms close-loop precision control, cycle time effectively shortened and improving production efficiency.
Oil temperature rise slowly
The system can restrain arising of oil temperature, so smaller oil cooling system can be used in the machine.PQ control

Control pressure and flow simply by inputting simulated voltage of pressure & flow into the computer.
Low noise
Different from ordinary fixed pump injection molding machine, servo power-saving injection molding machine is working only when necessary. And working noise is less than LOG-A8 series, will be much quieter for your working area.



CNC Horizontal Precision Injection Molding Machine 2400KN Clamping Force



■ The Injection Units

Short and forceful double-cylinder injection system is used to ensure the steady injection motion.The strain free fixed mold plate and screw assembly with optimized design help to reach better plasticing capacity and effect. PID temperature control regulate the speed and pressure of injection, pressure keeping, smelting, back pressure and other motions to ensure the quality of formed products and continuation of production.Auto material preparation, drooling proof,and anti cold start lapse functions ensure the high efficent,simple and safe operations.

■ The Hydraulic Units
High efficiency, Energy-saving and high precise proportional pressure and flow variable displacement pump system make the out of the hydraulic system matching the required power for entire machine operation without loss of high pressure throttle and overflow energy. As comparedwith constant displacement pump, t saves power by 30%~60%.A motor with same power may be fitted with an oil pump of bigger displacement and thus accelerates the speed of machine.Besides, the low oil temperature will prolong the service life of sealing elements.
Buffer device is used in every mold opening and clamping oil way to ensure steady mold opening and clamping operation without any impact.Besides, differential mold clamping operation is fitted to ensure high production efficiency.







SPECIFICATION HJF-240
  A B C
Screw Diameter Mm 50 55 60
Screw L/D Ration L/D 22.2 20 18.2
Shot Size(Theoretical) cm3 508 593 706
Injection Weight(PS) g 462 534 642
Injection Rate g/s 148 179 202
Injection Pressure MPa 180 160.8 128
Screw Speed rpm 0~180
Clamp tonnage KN 2400
Opening stroke Mm 490
Space Between Tie Bars mm 530*510
Max.Mold Height mm 530
Min.Mold Height mm 200
Ejector Stroke mm 165
Ejector Tonnage KN 70
Max.Pump Pressure MPa 16
Pump Motor Power KW 18.5
Heater power KW 11.65
Machine Dimension(L*W*H) M 5.4*1.5*2
Machine weight T 7
Oil Tank Capacity L 340
