Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line

Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line
Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line

Large Image :  Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line

Product Details:
Place of Origin: Zhejiang ,China
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF240
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard Export Package
Delivery Time: 30 days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 5000pcs per year

Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line

Description
Structure: Horizontal Injection Molding Machine Usage:: Electric Parts
Machine Weight:: 7T Clamping Force:: 2400KN
Space Between Tie Bar: 530*510mm Pump Motor Power: 18.5kw
High Light:

all electric injection molding machines

,

plastic products making machine

plastic pet bottle suppliers machine energy saving manufacturers for sale injection molding 300ml production line

  1. The rigid one-piece injection base supports the common slide rail for injection and screw movements.
  2. Highly optimized servo-hydraulic technology, with improved efficiency for lower energy consumption.
  3. The technologically matured Jupiter II Series convinces not only with rapid, smooth mold movements and its highly economical energy consumption. The latest upgrade to the Jupiter - called “Plus” - has brought significant additional improvements.
  4. High efficiency, Energy-saving and high precise proportional pressure and flow variable displacement pump system make the out of the hydraulic system matching the required power for entire machine operation without loss of high pressure throttle and overflow energy.

  5. The machine use the high-performance servo dynamic control system,the oil pump as the power source,having the characteristics as follow:high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production.

  6.

    Visiable lubrication system: on time clean, avoid cast steel parts abrasion and broken.

    Oil treasure: Filter of hydraulic oil, good for pump and valves.

    Long working life: Imported spare parts and updated version.

    Aftersales service: Professional & timely.

Plastic Pet Bottle Horizontal Injection Molding Machine 300ml Production Line 0

1. High energy savings
Under normal operating conditions, compared with conventional
hydraulic injection molding machines, energy savings of 20-80%
can be achieved.
2. Molding stability
Compared with conventional injection molding machines repeatability is greatly improved due to servo motor closed-loop control.
3. Quick response
Featuring a dynamic servo motor with a response time of only 0.05secviding lower platen stress and higher mold force stability, reducing mold wear and improving molded product stability.

Characteristic

The machine use the high-performance servo dynamic control system, the oil pump as the power source, having the characteristics as follow: high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.

High Energy saving

SPECIFICATION HJF-240
  A B C
Screw Diameter Mm 50 55 60
Screw L/D Ration L/D 22.2 20 18.2
Shot Size(Theoretical) cm3 508 593 706
Injection Weight(PS) g 462 534 642
Injection Rate g/s 148 179 202
Injection Pressure MPa 180 160.8 128
Screw Speed rpm 0~180
Clamp tonnage KN 2400
Opening stroke Mm 490
Space Between Tie Bars mm 530*510
Max.Mold Height mm 530
Min.Mold Height mm 200
Ejector Stroke mm 165
Ejector Tonnage KN 70
Max.Pump Pressure MPa 16
Pump Motor Power KW 18.5
Heater power KW 11.65
Machine Dimension(L*W*H) M 5.4*1.5*2
Machine weight T 7
Oil Tank Capacity L 340
