Double Toggle Clamping Unit Injection Molding Machine 3600KN High Efficiency

China Double Toggle Clamping Unit Injection Molding Machine 3600KN High Efficiency supplier

Large Image :  Double Toggle Clamping Unit Injection Molding Machine 3600KN High Efficiency

Product Details:

Place of Origin: China
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF360

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: Negotiation
Packaging Details: standard export packing
Delivery Time: 30 days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 100 sets one month
Contact Now
Detailed Product Description
Machine Typehydraulic Type: Hydraulic Toggle Type Clamping Force: 3600 KN
Structure: Horizontal Plasticizing Way: By Screw
Usage: Plastic Products Space Between Tie Bar: 680mm*680mm
Oil Tank Capacity: 620L Heat Power: 17.25kw

double toggle high pseetid injection molding machine injection pressure 275 Mpa screw speed 0~180

 The Characteristic Of HAIJIA Special Machine

The Hydraulic Units
High efficiency, Energy-saving and high precise proportional pressure and flow variable displacement pump system make the out of the hydraulic system matching the required power for entire machine operation without loss of high pressure throttle and overflow energy. As comparedwith constant displacement pump, it saves power by 30%~60%. A motor with same power may be fitted with an oil pump of bigger displacement and thus accelerates the speed of machine.Besides, the low oil temperature will prolong the service life of sealing elements.
Buffer device is used in every mold opening and clamping oil way to ensure steady mold opening and clamping operation without any impact.Besides, differential mold clamping operation is fitted to ensure high production efficiency.

HJF360 High quality hydraulic injection Molding Machine
Injection Unit                                                                       A                      B
Screw Diameter mm                                    65                      70
Screw L/D Ratio L/D                                   21.2                    19.4
Shot Size (Theoretical) cm3                                    1128                  1306
Injection Weight (PS) g                                     1026                  1180
Injection Rate g/s                                     275                     328
Injection Pressure Mpa                                     183                     160
Screw Speed rpm                                               0~180
Clamping Unit
Clamp Tonnage                      KN                                               3600KN
Toggle Stroke                        mm                                                  700
Space Between Tie Bars       mm                                               680*680
Max.Mold Height                     mm                                                   670
Min.Mold Height                      mm                                                   240
Ejector Stroke                         mm                                                   160
Ejector Tonnage                     KN                                                     62
Others
Max.Pump Pressure              Mpa                                                    16
Pump Motor Power                KW                                                     37
Heat Power                            KW                                                     17.25
Machine Dimension                 m                                                 6.3*1.9*2.4
Machine Weight                       t                                                       12


hydraulic injection molding machine,hydraulic components of eurpean and american brands with different circuit design ensure locking fast,low nosie,shortent the molding cycle,improve production efficiency
