18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder

China 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier
18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier 18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder supplier

Large Image :  18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder

Product Details:

Place of Origin: Zhejiang ,China
Brand Name: HAIJIA
Certification: CE ISO9001
Model Number: HJF240

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard Export Package
Delivery Time: 30 days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 5000pcs per year
Contact Now
Detailed Product Description
Structure: Horizontal Injection Molding Machine Usage:: Electric Parts
Machine Weight:: 7T Clamping Force:: 2400KN
Space Between Tie Bar: 530*510mm Pump Motor Power: 18.5kw

injection molding machine for making plastic syringe holder manufacturers disposable cap for sale mould production line





1.Optimized clamping unit provides lower energy consumption and faster movements for reduced cycle times.

2.The redesigned toggle kinematics for higher efficiency and lower energy consumption for small and large machines.

3.The redesigned clamping unit providing lower platen stress and higher mold force stability, reducing mold wear and improving molded product stability.

6.Due to new toggle design with optimized kinematics.

Take 200-ton clamping unit for example
Vm: Moving speed of movable platen
Vo: Moving speed of oil cylinder



18.5kw Power Plastic Injection Molding Machine For Plastic Syringe Holder

1. High energy savings
Under normal operating conditions, compared with conventional
hydraulic injection molding machines, energy savings of 20-80%
can be achieved.
2. Molding stability
Compared with conventional injection molding machines repeatability is greatly improved due to servo motor closed-loop control.
3. Quick response
Featuring a dynamic servo motor with a response time of only 0.05sec
4. Quiet operation
The machine runs at much lower noise levels, particularly in low speed applications.
5. Reliable holding pressure
Compared with traditional hydraulic machine the holding pressure is more stable and does not have limitation.
16 Better oil temperature stabitily

■ Computer Controller PLC
Professional injection moulding machine controller with software and hardware of industrial standard is convenient to expansion and revision of performance.
Adopting double CPU control makes high speed.
Mainly adopting PID control, the control accuracy reaches±1°.
Has the function of network management, improving efficency.
■ The Mould Adjusting Units
The automatic mold adjusting device driven by hydraulic motor adopts gear coupling drive, features steadiness, high-efficiency and saving mold loading time.

Characteristic

The machine use the high-performance servo dynamic control system, the oil pump as the power source, having the characteristics as follow: high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.

High Energy saving

Under the ideal working state, Power consumption is 40% less than that of variable displacement pump and 70% less than that of fixed displacement pump, save the cost effectively.

SPECIFICATION HJF-240
  A B C
Screw Diameter Mm 50 55 60
Screw L/D Ration L/D 22.2 20 18.2
Shot Size(Theoretical) cm3 508 593 706
Injection Weight(PS) g 462 534 642
Injection Rate g/s 148 179 202
Injection Pressure MPa 180 160.8 128
Screw Speed rpm 0~180
Clamp tonnage KN 2400
Opening stroke Mm 490
Space Between Tie Bars mm 530*510
Max.Mold Height mm 530
Min.Mold Height mm 200
Ejector Stroke mm 165
Ejector Tonnage KN 70
Max.Pump Pressure MPa 16
Pump Motor Power KW 18.5
Heater power KW 11.65
Machine Dimension(L*W*H) M 5.4*1.5*2
Machine weight T 7
Oil Tank Capacity L 340
